TOTAL FORMING ANALYSIS – (TFA™) PROCESS MONITORING AND GOB WEIGHT CONTROL

Using the Cylinder Performance Monitoring System (CPMS®) feature of the TWT® allows the operator to see inside the initial forming cycle of the container manufacturing process. Timing commands, gob delivery, air pressures, linear movement, and exhaust temperatures are all items that the forming department needs to control and are easily monitored by the CPMS®. The system allows the operator to see what is going right or wrong – instantly. This applies to both NNPB processing and production in conventional Blow & Blow or Advanced Blow & Blow.

The TFA can be used to:

  • Control gob weight through tube height on needled control
  • Reduce MDT (Machine Dead Time) to safely improve production parameters.
  • Improve container quality by better process monitoring and control.
  • Identify problems in the forming of the parison.
  • Increase the speed and percentage of pack in any forming process, Press & Blow or Blow & Blow.

TFA™ Customer Inquiry:

Company: *
Name: *
Address: *
E-mail: *

Machine Configuration


IS Machine Manufacture: *
Center Distance of Machine: *
# of Sections: *
# of Electronic Sections Required: *

Feeder Mechanism


Feeder Mechanism Manufacture: *
Tube Control: *
Needle Control: *

Factory Conditions


Available Power (VAC): *
Ambient Temperature near desired Operators Station: *

Timing System


OEM of Timing System: *

Cable Lengths


Cable Length from front of section frame to desired location of TFA™ Distribution Box: *

^ Designated as “A” Cable is Maximum of 12 meter.

Cable Length from TFA™ Distribution Box to desired location of TFA™ Main Panel: *

^ Designated as “B” Standard Cable is 30 meter. Additional Length will be extra cost.

Cable Length from Existing Timing System to TFA™ Main Panel: *

^ Designated as “C” Standard Cable is 10 meter. Additional Length will be extra cost.

Cable Length from desired Location of TFA™ Operators Screen to TFA™ Main Panel: *

Designated as “D” Standard Cable is 30 meter. Additional Length will be extra cost.

TFA Layout
